USB2 Grab !
Supports USB 2 ! Now Supports Windows 7 !
Microsoft MSN Windows Live Messenger Compatible ! For Video Conferencing

USB2 Grab!-AV and USBGrab!-X Video Capture Adaptors for PC

USB2Grab! is available in 2 models, USB2Grab!-AV with audio input and USB2Grab!-X without audio input. The model without audio input uses your existing soundcard to capture the sound. This makes it very cost effective and also avoids any problem of having two sound capture devices which might otherwise clash and cause problems as you can imagine. Ideal for Video Streaming applications. USB2Grab!-AV captures both Audio and Video and thereby ensures Audio and Video Sync in motion video is perfect. Even with long captured videos. Ideal for video Editing applications.

The USB2 Grab! Video Capture Adapter is the ideal way to bring smooth full motion video and also high quality still images into your computer from various standard video sources, such as video cameras, camcorders, VCRs or TV tuners. You don't need special firewire cameras or DV camcorders with this New Generation USB 2.0 Video Grabber device. Any ordinary VCR, Camera or camcorders are just fine. Designed using own specialised chips makes this video frame grabber better than other similar products on the market. Advanced compression technology and software enable unparalleled throughput and video capture in AVI or MPG format up to 30 frames per second and 720 x 576 resolution. Our technology gives the user superior live video performance at a realistic price.

The captured video can be used with the included or third party popular video and imaging capture applications for Microsoft Windows. Such as video streaming, web page design, and video conferencing. Video clips and still images can be incorporated into your web pages or used with desktop presentations.

You can also incorporate video clips or still images from family events or business meetings onto your web site. Stream your video to your employees or friends using various software packages. Video conference is possible using software such as Microsoft NetMeeting or CU-SeeMe. The USB2 Grab! Video Capture Adapter gives you the ability to create video Email messages. Creative webmasters can incorporate video clips or still images onto web sites. You can even use it for full screen Video Game Display applications on your laptop computer!

Installation is a true plug and play experience. Install the included software drivers, snap USB2 Grab! USB cable to your PC and attach your VCR, camera, camcorder or any other video source to the Composite Video RCA or S-Video input jacks. Now you are ready to begin capturing live video, creating amazing still images, or Video Conferencing. USB2 Grab! is the best ideal companion for your portable and workstation video applications.


Features Summary:
  • USB 2.0 High Speed Device for highest possible frame rate and best video recording performance.
  • Supports full motion video capture
  • Supports SnapShot still image capture
  • Standard Composite Video RCA input plus High Resolution S-Video input.
  • Full Motion video - Up to 30 fps
  • Full Motion Video - Up to 720 x 576 resolution.
  • Allows capturing AVI file format for applications for which MPEG is inadequate.
  • Encodes Mpeg 1 or Mpeg 2 format directly using InstantMPEG Technology for creating VCD or DVD movies
  • Any NTSC or PAL video source can be used.
  • Easy plug-and-play operation.
  • Audio goes through your existing standard sound card. Simple.
  • Fully compatible with popular video conferencing software and Windows applications.
  • Compatible with TWAIN applications for still image capture.
  • Supports brightness, contrast, hue, saturation, sharpness control.
  • Easy BURN function can burn movies onto disk and create VCD, SVCD or DVD title
  • Powerful video editing functions. Special effects, title effects,transitions etc.
  • Powered by the USB port. 5VDC, 250mA(max)
  • Small dimensions and portable. 81x30x15mm can be used even on notebook PCs.

  • Technical Specifications and Features
    - Video Inputs: One RCA Composite Video Input, One S-Video SVHS Input
    - Video Standards: NTSC, PAL and SECAM multi system support.
    - Performance: Up to 25 fps at 720x576 (PAL), Up to 30 fps at 720x480 (NTSC)
    - Full Motion Capture:
       - AVI Format from 160x120 to 720x576 Resolution
       - MPG Format from 320x240 to 720x576 Resolution
    - MPEG bit rate adjustable from 192Kbps to 10000Kbps
    - USB 2.0 Compatible Device
    - Cable Length: 1.3m
    - Environmental Operating Temperature: 0-50 Degrees Celcius.
    - Note: Specifications are subject to change without notice.

    Minimum System Requirements:
  • USB 2.0 equipped computer
  • Pentium 3 500MHz or above
  • 128MB RAM
  • Windows 98SE/ME/2000/XP/Windows7

  • Applications
    - Medical Video and Still Shot capture.
    - Telemedicine
    - Security and Surveillance Monitoring Systems
    - Security Picture ID Card Picture Capture
    - Video Broadcasting over Internet (CALL for a demo!)
    - Video Conferencing over POTS, ISDN, LAN, WAN
    - Golf Swing Analysis. Compatible with "GolfCoach", "Swinger" and "Computer Coach" Software
    - Animated Video and Still Capture
    - Video Email Messages
    - Website Development
    - Video Streaming
    - TWAIN Applications
