Interactive Audio & Video Server Over Internet
Features & Benefits
  • Designed For Optimum Audio/Video Server performance.
  • View 30fps full motion live video in remote sites from your PC
  • Transmit audio in both directions by using sound card inside PC
  • Control a Cameras on another continent remotely over the web
  • Allow multiple users could view real-time events anytime and from anywhere in the world, over the Internet
  • Store audio/video and replay them anytime over the Internet
  • Plug & Play without requiring custom hardware, software or ongoing maintenance
  • Built-In Web Server, the video is grabbed, compressed and transmitted to your PC through Internet, Intranet or telephone line
  • Easy System configuration (via HTTP Home Page or RS-232)
  • Use a standard Web Browser as your client application
  • Built-In General Purpose I/O for remote Control
  • Video adjustable for hue, contrast, saturation and brightness
  • Support upload HTML file to FLASH ROM for home page customization
  • Support QUAD function
  • Industrial 19" 1U Rack Mount or desktop
Video Input Support NTSC/PAL composite video
4 BNC Video Input Connectors
Built-in 75 ohm Terminator Switch
TV/Monitor Output Support NTSC/PAL Video Output
One RCA Composite Output
Remote Control Input/Output 4 Remote Control In/Out Points
Photo-Couple Digital Input
24V/200mA Relay Output
Audio Input/Output 4 Audio Input/Output
Ear-Phone output
Line-In Input
Compression Standard Support H.263, M-JPEG, JPEG Standards
Image Quality 30fps
Hardware 32bits CPU, 64MB DRAM
8MB Flash-ROM For Firmware
One RS-232 Serial Port
One RS-232/422/485 Serial Port
One 100 BaseTX Ethernet Port
Front Panel 16 digits LCD Display
Built-In Mini Web Server
Browser Compatibility Win 95/98 running Netscape Navigator 4.0 or MS Internet Explorer 4.0 or above
Communication Protocol Support TCP/IP, PPP, HTTP Support
Power Supply 100-240VAC, 50-60HZ
Size/Weight 381mm (L) x 164mm (W) x 41mm (H)
19" 1U Rack Mountable Design
Software OYO Viewer
